◆Each time is 0.2 seconds high speed, low power consumption, simple automatic operation.
◆Applicable to the wide range of materials,compatible with various loading and unloading methods.
◆Tailift wisdom of exclusive software, easy to operate smoothly.
◆Cloud management and maintenance, real-time monitoring of operation.
◆The daily maintenance is simple and low cost.
◆Without making molds, free to design complex shapes and production at any time.
◆The 13 axes move simultaneously, the bending movement is smooth, and the operation is highly coordinated.
| Specification | unit | TBC2000 | |||
|---|---|---|---|---|---|
| Minimum accuracy | mm | 0.01 | |||
| Fastest bending speed | sec | 0.5sec秒/each刀 | |||
| Maximum bending width | mm | 2000 | |||
| Maximum bending size | mm | 2000x1500mm | |||
| Bending height | mm | 170mm | |||
| Rated voltage | V | 380V | |||
| Peak power | KW | 23KW | |||
| Average power | KW | 2.2KW | |||
| Noise | dB | 40dB | |||
| Dimensions(LxWxH) | cm | 400 x 255 x 310 | |||
| Total weight | tons | 18 | |||
| Operating environment | windows 7 up ad | ||||
| Maximum bending thickness | mm | MS 1.5mm | |||
| Minimum material thickness | mm | 0.35mm | |||
| Minimum inner size of four sides forming | mm | 110mm x 280mm | |||
| Minimum inner size of bilateral forming | mm | 110mm | |||
| Number of axes | 13 | ||||
